2 Pole 40A Schneider Switch Disconnector
Brand - Schneider
Model - EZ9S16240
Range - Easy9
Product or Component Type - Switch
Device short name - Easy9 switch
Switch Application - Distribution
Poles - 2P
Utilisation Category - AC-22A
Suitability for Isolation - Yes
Complementary
[Ie] rated operational current - 40 A at 400 V 50/60 Hz
[Ue] rated operational voltage - 400 V AC 50/60 Hz
[Icm] rated short-circuit making capacity - 0.6 kA
[Icw] rated short-time withstand current - 0.48 kA during 1 s
[Ui] rated insulation voltage - 500 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage - 4 kV
Control type - Toggle
Local signalling - ON/OFF indication
Contact position indicator - Yes
mounting mode - Clip-on
mounting support - DIN rail
9 mm pitches - 4
Height - 81 mm
Width - 36 mm
Depth - 66.5 mm
Colour - Grey
Mechanical durability - 8500 cycles
Electrical durability - 1500 cycles
Connections - terminals Tunnel type terminal (top or bottom) 1…35 mm² rigid
Tunnel type terminal (top or bottom) 1…25 mm² flexible
Tightening torque - 3.5 N.m
Environment
Standards - IEC 60947-3
Product certifications - CE
IP degree of protection - IP20 conforming to IEC 60529
Tropicalisation - 2
ambient air temperature for operation - 5…55 °C
ambient air temperature for storage - 5…70 °C
Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 7.7 cm
Package 1 Width - 3.6 cm
Package 1 Length - 8.5 cm
Package 1 Weight - 162 g
Unit Type of Package 2 - BB1
Number of Units in Package 2 - 6
Package 2 Height - 9 cm
Package 2 Width - 9 cm
Package 2 Length - 23 cm
Package 2 Weight - 1.034 kg
Unit Type of Package 3 - S03
Number of Units in Package 3 - 72
Package 3 Height - 30 cm
Package 3 Width - 30 cm
Package 3 Length - 40 cm
Package 3 Weight - 12.895 kg
wedabima.com and D Factor Group make no warranty or representation for any products, services, deals and transactions between the user and the advertisers. Users strictly at their own risk.
Three Phase Contactor for sale colombo price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Pradeep electrical Company Limited is a pioneer in the field of Electrical Items Sale & Services. Pradeep e, etc... Find best deals from වැඩබිම
ContactSingle Phase Contactor price in balangoda price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Pradeep electrical Company Limited is a pioneer in the field of Electrical Items Sale & Services. Pradee, etc... Find best deals from වැඩබිම
Contact600A 3P - 50KA Schneider Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - LV563316 Range of Product - EasyPact CVS400...630 Product Name -, etc... Find best deals from වැඩබිම
